Lever block VL

Lever block VL

•Compact design and robust, deep drawn, stamped steel construction

•High quality materials ensure light weight without infringing reliability

•Low weight. small mou nting sizes and small lever forces at fullload

•Hand lever operates with little effort due to optional gear ratio

•Premium arade alloy load chain

•Drop-forged and expertly heat freated hooks for great strength and long wearing

Lever block VL

型号 MODEL	起重量 (T) CAPACITY	起升高度 (M) STANDARD LIFT	实验载荷 (T) TEST LOAD	载荷中心距 (mm) LOAD CENTER DISTANCE	满载时起动力 (N) NORMAL LIFTING FORCE	起重链行数 No.OF LOAD CHAINS	(MN) 2/3RER OF LOAD CHAIN	净重 (KG) N.W.	装箱毛重 (KG) G.W.	装箱尺寸 (长 × 宽 × 高 CM) PACKING MEASUREMENT (L×W×H)
VL0.8	0.8	1.5	1	285	25	1	6	7	9.4	33×16×13
VL1	1	1.5	1.8	315	33	1	6	7	9.4	33×16×13
VL1.6	1.6	1.5	2	340	34	1	7.1	11	14.5	43×18×16
VL2	2	1.5	3	380	34	1	8	15.5	17	44×19×17
VL3.2	3.2	1.5	4.5	475	35	2	9	20	23	50×20×18
VL6.3	6.3	1.5	7.5	600	39	2	9	28	32	53×21×21
VL9	9	1.5	12	700	41	3	9	47	50	82×32×15
