DIN763 Long Link Chain

Product Name	DIN763 long link chain
Material	Sainless Steel or Carbon Steel
Structure	Welded
Size	1.5mm~32mm
Type & Grade	DIN763
Standard	German Standard
Surface Treatment	Self colored, electric galvanized, hot dip galvanized
Packing	Gunny bag, Woden bag, Plastic reel+carton, Plastic drum, Steel drum, any other package request as request.

Specification Sheet:

DIN763Long Link Chain

Size d(mm)		Inside Length		Outside Width		Working Load(kg)	Test Load(N)	Breaking Load(N)	Weight Per M(kg)
mm	±mm	mm	‌±mm	mm	‌±mm
2	0.5	22	1	8	0.4	25	800	1200	0.06
2.5		24	1.1	10	0.5	40	800	2000	0.1
3		26	1.2	12	0.6	55	1050	2600	0.15
3.5		28	1.3	14	0.7	80	1540	3850	0.2
4		32	1.5	16	0.8	100	2500	6250	0.27
4.5		34	1.7	18	0.9	128	3000	8000	0.35
5		35	1.8	20	1	160	4000	10000	0.43
5.5		38.5	1.8	22	1.1	195	4200	10500	0.52
6		42	2	24	1.2	200	5000	12000	0.63
7		49	2.5	28	1.4	300	7500	19000	0.86
8		52	2.5	32	1.6	400	10000	25000	1.1
8.5		56	2.8	34	1.7	460	10500	26250	1.25
9		59	3	36	1.8	530	10500	32000	1.41
10	1	65	3.2	40	2	630	16000	47000	1.75
11		72	3.4	44	2	790	18500	46250	2.11
12		78	3.6	48	2.3	940	18500	56500	2.55
13		82	4	52	2.5	1000	25000	63000	2.95
16		100	5	64	3.2	1100	42000	107000	4.45
18		113	5.2	70	3.2	2300	47300	120000	5.65
19		119	5.6	72	3.4	2370	47300	142000	6.25
20		120	6	75	3.8	2500	63000	160000	7
22		127	6	82	4	3170	50000	180000	8.55
25		140	6.6	85	4.2	4090	81700	245000	10.9
28		152	7	96	4.7	6000	120000	300000	13
32		171	7.8	108	5.2	8000	160000	400000	18.2
