En 818-2 Standard G80 LIFTING CHAIN

G80 LIFTING CHAIN

Material:	20MN2
Standard:	EN818-2
Size:	6,8,10,13,16,18,20,22,26,30,32 ect.
Package:	Gunny Bag, Plastic Drum, Iron drum
Grade:	G80
Finish	Yellow/ White Galvanized. Black, Plastic coated.

SIZE d*P mm	WIDTH (MM)		BREAKING FORCE T	WORKING LOAD T	TESTING LOAD KN	WEIGHT KG/METER
SIZE d*P mm	INSIDE WIDTH	OUTER WIDTH	BREAKING FORCE T	WORKING LOAD T	TESTING LOAD KN	WEIGHT KG/METER
6*18	7.5	21	4.4	1.1	27	0.79
7*21		24	6	1.5	37	1.07
8*24	10	28	8	2.0	48	1.38
10*30	12	35	13	3.2	76	2.20
11*43	12	36	16	3.8	92	2.33
12*36	15	42	18	4.6	109	3.10
12.5*38	15	42	22	4.9	117	3.30
13*39	16	46	22	5.0	128	3.80
14*42	18	49	26	6.3	150	4.13
14*50	17	48	26	6.3	150	4.33
15*46	20	52	28	7.0	168	5.17
16*48	20	56	32	8.0	192	5.63
16*49	24	60	32	8.0	192	5.71
16*64	24	60	32	8.0	192	5.11
18*54	23	63	40	10.0	246	6.85
18*64	21	60	40	10.0	246	6.60
19*57	24	63	45	11.3	270	7.70
20*60	25	70	50	12.5	300	8.60
22*65	28	74	60	15.3	366	10.70
22*66	28	77	60	15.3	366	10.20
22*86	26	74	60	15.3	366	9.50
24*72	32	82	72	18.0	432	12.78
24*86	28	79	72	18.0	432	11.60
26*78	35	91	85	21.3	510	14.87
26*92	30	86	85	21.3	510	13.70
30*90	38	105	115	28.3	678	19.60
30*108	34	98	115	28.3	678	18.00
32*96	40	106	250	32.2	772	22.29
Manual measurement,there may be slight difference
